Cable Specification
| RG59 coaxial cable (BC type) |
CONDUCTORS | COND.MATERIAL | BC |
| CONSTRUCTION | 0.81±0.0030 |
DIELECTRIC | DIAMETER | 3.7±0.15mm |
| MATERIAL | FPE |
SHIELDED | BRAIDING MATERIAL | BC |
| BRAID CONSTRUCTION | 64/0.12±0.005mm |
OUT JACKET | DIAMETER | 6.0±0.2mm |
| MATERIAL | PVC/PE/LSZH |
Color |
| Black/White/Green or customized |
RG59 coaxial cable (CCS type) |
|
CONDUCTORS | COND.MATERIAL | CCS |
| CONSTRUCTION | 0.81±0.0030 |
DIELECTRIC | DIAMETER | 3.7±0.15mm |
| MATERIAL | FPE |
SHIELDED | BRAIDING MATERIAL | AM |
| BRAID CONSTRUCTION | 64/0.12±0.005mm |
OUT JACKET | DIAMETER | 6.0±0.2mm |
| MATERIAL | PVC/PE/LSZH |
Color |
| Black/White/Green or customized |
Specifications: |
INNER
CONDUCTOR | Material | Copper/CCS |
Diameter | 0.584mm |
INSULATION | Material | Solid PE |
Diameter | 3.70mm |
Braiding | Material2 | Copper Wire |
Diameter | 112*0.12mm |
JACKET | Material | PVC/PE/LSZH |
Diameter | 6.0mm |
CHARACTERISTIC
IMPEDANCE | 75ohms±2 |
Nominal Capacity | 67(pf/m) |
Attenuation
At 20℃ | 3.61 [ dB/100m@10MHZ] |
7.87 [ dB/100m@50MHZ] |
11.15 [ dB/100m@100MHZ] |
16.08 [ dB/100m@200MHZ] |
22.97 [ dB/100m@400MHZ] |
31.82 [ dB/100m@700MHZ] |
36.42 [ dB/100m@900MHZ] |
39.37 [ dB/100m@1000MHZ] |
