Cable used for security protection, usually used to protect buildings, walls or other boundaries.
Product Name | Shield or unshielded 2 / 4 / 6 / 8 / 12 / 20 Cores CCA or bare copper conductor material fire alarm cable |
Color | White |
Packaging | 100/roll;200/roll/customized |
Payment terms | T/T in advance, Trade Assurance , L/C |
MOQ | 10KM |
Cable Specification | ▲Conductor:bare copper or tinned copper or CCA or CCS conductor
▲Insulation: PVC,PE,HDPE
▲ Separator: PE tape
▲Jacked: PVC-flame proof; LSZH, UL-CM,CMR
▲Cores: 2, 4, 6, 8, 12, 14,16,18,20
▲Used for alarm mechanisms or security system |
Specification to choose as your requirement as followings
2Cx22AWG | 2CX7/0.20mm BC/CCA/Tinned CCA I.D:1.1mmPVC O.D:3.2mmPVC |
4Cx22AWG | 4CX7/0.20mm BC/CCA/Tinned CCA I.D:1.1mmPVC O.D:3.8mmPVC |
6Cx22AWG | 6CX7/0.20mm BC/CCA/Tinned CCA I.D:1.1mmPVC O.D:4.1mmPVC |
8Cx22AWG | 8CX7/0.20mm BC/CCA/Tinned CCA I.D:1.1mmPVC O.D:4.8mmPVC |
10Cx22AWG | 10CX7/0.20mm BC/CCA/Tinned CCA I.D:1.1mmPVC O.D:5.2mmPVC |
12Cx22AWG | 12CX7/0.20mm BC/CCA/Tinned CCA I.D:1.1mmPVC O.D:5.8mmPVC |
2Cx22AWG | 2CX7/0.20mm BC/CCA/Tinned CCA I.D:1.1mm PVC+AL+7/0.20mm drain wire O.D:3.5mm PVC |
4Cx22AWG | 4CX7/0.20mm BC/CCA/Tinned CCA I.D:1.1mm PVC+AL+7/0.20mm drain wire O.D:4.2mmPVC |
6Cx22AWG | 6CX7/0.20mm BC/CCA/Tinned CCA I.D:1.1mm PVC+AL+7/0.20mm drain wire O.D:4.5mmPVC |
8Cx22AWG | 8CX7/0.20mm BC/CCA/Tinned CCA I.D:1.1mm PVC+AL+7/0.20mm drain wire O.D:5.2mmPVC |
10Cx22AWG | 10CX7/0.20mm BC/CCA/Tinned CCA I.D:1.1mm PVC+AL+7/0.20mm drain wire O.D:5.4mmPVC |
12Cx22AWG | 12CX7/0.20mm BC/CCA/Tinned CCA I.D:1.1mm PVC+AL+7/0.20mm drain wire O.D:6.2mmPVC |
Buyer's Guide
Requirement Analysis:
Determine the area to be protected, including length and height.
Consider the installation environment, such as outdoor walls or indoor boundaries.
Technical Requirements:
Choose the appropriate alarm line type based on security needs, such as a single coil or multi-coil system.
Confirm whether the system has anti-interference capabilities and low false alarm rates.
